Technical Specifications

Key Benefits

The Exterior Surface: Engineered for Extreme Climates

• Ultimate ASA Shield: Extruded simultaneously with the uPVC core, the outer Acrylonitrile Styrene Acrylate (ASA) layer provides elite resistance to intense UV radiation, preventing chalking and yellowing.

• Mechanical Embossing Durability: The in-line textured embossing diffuses harsh sunlight to achieve a premium low-gloss matte facade. This rugged texture naturally repels dust and anti-statically resists construction site scratches.

• Infrared Heat Reflection: ASA pigments reflect near-infrared solar rays, drastically lowering profile expansion and contraction to ensure smooth hardware operation over decades.

• Authentic Timber Aesthetics: The indoor foil replication eliminates plastic sheen, offering the deep tactile grains and rich tones of luxury hardwoods (like Golden Oak and Walnut).

• Industrial PUR Fusion: The foil is permanently bonded using high-performance Polyurethane (PUR) reactive hot-melt glue. It chemically cross-links to prevent bubbling or delamination under room humidity shifts.

• Stain & Abrasion Resistant: Easy to clean with basic soap and water, the non-porous indoor face resists daily finger marks, dust, and indoor wear.

• Galvanized Steel Compatible: Features dedicated internal chambers to easily accommodate thick steel reinforcements for high-wind compliance.

• Class B1 Fire Safety: Formulated with self-extinguishing compounds to meet strict international commercial fire protection guidelines.

Applications & Customization

• Window Systems: Sliding windows, Casement windows, Single/Double Hung windows, Tilt & Turn windows, and Fixed/Top-Hung designs.

• Door Systems: Sliding doors, Casement entry doors.

• Glazing Options: Supports single, double, and triple glazing (up to 32mm thickness).

Frequently Asked Questions (FAQs)

• Q: What is the primary advantage of Haitec's Asymmetric profiles compared to standard double-sided laminated profiles?

• A: The ultimate advantage is a massive cost reduction through smart value engineering. Double-sided laminated profiles are expensive due to the high cost of exterior-grade foils and double lamination processing. By replacing the exterior foil with an ASA co-extruded embossed layer, we lower your raw material and manufacturing costs significantly. This allows you to win commercial bids with a far more competitive price per meter while still maintaining an elite, premium product line.

• Q: Why do you suggest avoiding exterior laminated foils for dark-colored outdoor facades?

• A: In many architectural projects, putting highly detailed wood-grain foils on the building's exterior is actually a case of "over-decoration." From the street or a distance, the intricate grain of a wood foil cannot be seen; it simply looks like a solid matte color. More importantly, exterior foils are exposed to severe weathering, bird droppings, wind-blown sand, and intense heat, which increases long-term maintenance risks. Our ASA co-extruded embossed exterior delivers the exact same premium solid matte look from the outside but with vastly superior climate resistance and a much more attractive price tag.

• Q: Can the interior laminated foil peel or bubble over time due to seasonal humidity?

• A: No, peeling is impossible. We utilize high-grade, reactive Polyurethane (PUR) hot-melt adhesive applied through an automated, tension-controlled lamination line. The PUR adhesive cross-links chemically to create an incredibly powerful, moisture-resistant bond that easily withstands interior climate changes without bubbling or lifting.

• Q: What is your Minimum Order Quantity (MOQ)?

• A: Our standard minimum order quantity is 10 tons per order. However, given that the ocean freight cost difference between a 20GP and a 40HQ container is minimal, placing an order of 26–28 tons (a full 40HQ container load) will significantly optimize your shipping logistics and give you a more advantageous product unit price.

• Q: What is your standard production lead time?

• A: Our standard production lead time is 40 days.

Partner with Haitec Profile Today
